Primetals Upgrades E&A of RH Plant & Ladle Furnace at CSN Plant
Nacional in Volta Redonda in Rio de Janeiro State in Brazil. The electrics and automation systems of a RH degassing plant, a ladle furnace and the common alloy system were replaced with new versions. The RH plant and the ladle furnace were brought back into operation within only five months of order signing. The Provisional Acceptance Certificates have already been issued by CSN. To increase availability, new remote IO panels were added in case of any incident in the E-rooms.
Primetals Technologies scope included the engineering for electrics and automation, HVAC (Heating, Ventilation, Air Conditioning) systems, fire fighting systems and the installation of all equipment supplied. The equipment comprised MCCs (Motor Control Centers), drives cubicles (both DC and AC), auxiliary panels for voltage distribution, lighting, and junction boxes, PLCs and remote IO, a gas analyzer, an electrodes control system, a data acquisition system, the HVAC, including condensers, evaporators and filters, control panel, detectors and valves for the fire-fighting system, as well as spare parts and installation materials like cables, trays, conduits and piping. In addition, Primetals Technologies offered erection services, the site supervision for erection and commissioning, and assisted operation.
The equipment of both plants was supplied, erected, commissioned and started-up in only 5 months after the contract signature. Primetals Technologies managed to start-up the ladle furnace even one week in advance to contractual schedule, even amidst all the difficulties and constrains imposed by the COVID-19 pandemic. Due to the bad conditions of a large amount of existing cables, vast quantities of cables had to be replaced. Critical path for the success of the project was the timely identification of cables to be replaced and generation of new interconnection diagrams during the installation phase.
The existing electrode control system of the ladle furnace was replaced by the Melt Expert package from Primetals Technologies. Melt Expert was commissioned by local Primetals Technologies employees with remote training and support from Austria.
CSN’s Presidente Vargas Steelworks is one of the largest steel producers in Latin America. It is located in Volta Redonda, Rio de Janeiro State, 141 km from the city of Rio de Janeiro, and has an annual production capacity of 5.8 million tons of steel. The two blast furnaces at Presidente Vargas Steelworks produce, together, 12.8 thousand tons of pig iron per day. The main production units are coke plant, sinter plant, melt shop, continuous casting, hot rolling, cold rolling, galvanizing, chromizing and electrolytic tinning.
